Hand-held laser welding machine

HANDHELD LASER WELDING MACHINE

Brief

HW series handheld laser welding machine: hydrocooling HW1500W/ hydrocooling HW2000W/ Air cooling HW1500WF-IPG/ HW1500-HL

Hand-held laser welding machine is a standard miniature laser welding machine with highly integrated control system, laser system, gas control and safety control system

Feature

Welding material: can weld stainless steel/ carbon steel/ aluminum alloy/ copper/ galvanized sheet and other materials

Welding form: can realize various forms of laser welding, such as stitching, lap and Angle joint weld

Using environment: indoor or outdoor welding work, suitable for all kinds of complex sheet metal/ hardware laser welding

Laser welding: fast welding speed, small deformation, beautiful welding seam, no polishing after welding, saving manpower

Advantage: simple operation, flexible and convenient, without professional welding knowledge, you can directly start the operation

Application: sheet metal, hardware, building materials, thin and thick plate laser welding of furniture and other industries, and thick plate laser backing welding, spot welding, etc

Specification parameter

No.ItemParameter
1ModelHW1500F-IPGHW1500F-HLHW1500HW2000
2Laser power1500W1500W1500W2000W
3Max power of whole machine5.5kW6kW8.5kW10.2kW
4laser wavelength1080±5nm
5Fiber lengthStandard 10m
6Working modeContinuance/ Modulation
7Vibration lens  width(laser swing)0~5mm
8Vibration lens  speed(oscillation frequency)0~300Hz
9Welding speed0~50mm/s(Different due to model, material, plate thickness, configuration requirements, etc)
10Cooling waywater chiller
11Welding plate thickness

0.4~4mm

(Different due to materials, speeds

0.4~4mm

(Different due to materials, speeds

0.4~4mm

(Different due to materials, speeds

0.4~4mm

(Different due to materials, speeds

12Welding crack

Without filler wire welding,≤0.3(Different due to model, plate thickness, workpiece)

With filler wire welding,≤0.5(Different due to model, plate thickness, workpiece)

13Power supply

AC220V,50/60Hz,Uniphase


AC220V,50Hz,UniphaseAC380V,50Hz,Three-phase
14Size, W*D*H, mm316*641*534347.5*720*667506*958*708506*958*708
15Machine weightAbout 53kgAbout 65kgAbout 132kgAbout 138kg
16Weight of unconnected optical fiber welding joint

About 0.81kg

About 0.8kg

17Weight of connected optical fiber welding jointAbout 1.72kg

About 1.70kg

Finished sample

Stainless steel fillet welding

Stainless steel fillet welding

Stainless steel impeller stack welding

Tube and plate welding

Aluminum wire filler welding

Aluminum wire filler welding

Carbon steel fillet welding

Stainless Steel Wire Filling Welding

Pipe Laser Welding

Stainless steel fillet welding

Copper Laser Welding
